SPECIFICATIONS
| DIMENSIONS & WEIGHTS | Double Cab | Double Cab 4WD | ||
| Overall length (with rear step bumper) | (mm) | 5,135 | ||
| Overall width | (mm) | 1,695 | ||
| Overall height | (mm) | 1,625 | 1,753 | |
| Wheelbase | (mm) | 2,985 | 3,000 | |
| Tread | Front | (mm) | 1,410 | 1,420 |
| Rear | (mm) | 1,410 | 1,420 | |
| Min. ground clearance | (mm) | 179 | 211 | |
| Kerb weight | (kg) | 1,531 | 1,699 | |
| Gross vehicle weight | (kg) | 2,618 | 2,786 | |
| Seating capacity | 5 | 5 | ||
| Min. turning circle (kerb-to-kerb) | (m) | 12.0 | 12.6 | |
| ENGINE | ||||
| Type | In-line, 4-cyclinder, SOHC | |||
| Displacement | (cc) | 2,892 | ||
| Compression ratio | 22.1:1 | |||
| Max. output (DIN Net) | 69 kW / 4,000 rpm | |||
| Max. torque (DIN Net) | 200 nm / 2,500 rpm | |||
| Fuel injection type | Mechanical | |||
| Fuel tank capacity | (litre) | 63 | 70 | |
| STEERING | ||||
| Gear type | Ball and nut | |||
| Power steering type | Engine speed sensing | |||
| DRIVE TRAIN | ||||
| Transmission type | 5-speed manual | |||
| Gear | 1st | 4.250 | ||
| 2nd | 2.356 | |||
| 3rd | 1.428 | |||
| 4th | 1.000 | |||
| 5th | 0.827 | |||
| Reverse | 3.656 | |||
| Final gear ratio | 4.100 | 4.444 | ||
| SUSPENSION | ||||
| Type | Front | Independent (double wishbone) | ||
| Rear | Rigid (leaf spring) | |||
| BRAKES | ||||
| Type | Front | Ventilated disc | ||
| Rear | Drum (leading / trailing with auto adjuster) | |||
